Loop Tape Roll – Single Sided – 16 mm x 50 m, White
16 mm wide, 50 m per roll, 2.9 N/25 mm peel, white.
| Construction | Loop Tape Roll |
| Width | 16 mm |
| Length | 50 m |
| Colour | White |
| Minimum order | 500 rolls |
Not ready to ask for a price? Just ask a question — an engineer replies, not a sales script.
Specification
| Construction | Loop Tape Roll |
|---|---|
| Width | 16 mm |
| Length | 50 m |
| Colour | White |
| Weight / roll | 0.32 kg |
| Peel strength | 2.9 N/25 mm |
| Shear strength | 12 N/cm² |
| Cycle life | 5,000 cycles |
| Service temperature | -20 °C to 80 °C |
| Rolls per carton | 68 |
| Minimum order | 500 rolls |
| Production lead time | 15-25 days after sample approval |
| Packing | Poly bag + carton, palletised for LCL |
| Certification | REACH, RoHS; OEKO-TEX on request |
What makes it different
- 16 mm width held to ±0.5 mm across the full run
- 2.9 N/25 mm peel measured on every lot
- Each 50 m roll weighs 0.32 kg; 68 rolls to a carton.
Other sizes in this construction
Same build, different width or length. Mixed sizes in one carton are fine.
| Size | Colour | MOQ |
|---|---|---|
| 16 mm x 25 m | Beige | 500 rolls |
| 50 mm x 50 m | Black | 500 rolls |
| 38 mm x 50 m | Black | 500 rolls |
| 38 mm x 50 m | Grey | 500 rolls |
| 25 mm x 50 m | Brown | 500 rolls |
| 75 mm x 25 m | Beige | 500 rolls |
| 75 mm x 25 m | Grey | 500 rolls |
| 16 mm x 25 m | Black | 500 rolls |
| 20 mm x 25 m | Grey | 500 rolls |
| 20 mm x 50 m | Grey | 500 rolls |
Need a custom width or die profile?
Send a drawing and we will confirm tooling cost and tolerance before you commit.
Talk to an engineerAbout this product
Produced to the same construction on every run, which is why converters reorder instead of resampling. Typical use is general purpose closures, bags, packaging and display mounting. Service temperature runs -20 °C to 80 °C.
Each 50 m roll weighs 0.32 kg; 68 rolls to a carton. Tolerance on width is ±0.5 mm, on die-cut profile ±0.3 mm.
Ordering and shipping
- Sold by the roll, carton or pallet — mixed widths allowed.
- EXW Xiamen, FOB or CIF to your port.
- T/T 30% deposit, balance against copy of B/L.
- Sample orders ship by courier in 7 days.
Choosing this construction
Bulk rolls are for converters who slit, coat or die-cut downstream. Check the splice count and the width tolerance at both ends of the roll before you build a line around it — a roll that measures 25 mm at the start and 24.4 mm at the end will jam a fixed guide.
Common questions
What is 16 mm hook and loop used for?
At 16 mm this construction is normally specified for cable bundling, apparel closures, small adjustable straps and light packaging. The width does not change the peel per unit width much, but narrower tape engages fewer hooks at the edge, which is where peeling starts — so if the joint opens repeatedly, go up one width rather than up one grade.
Are the rolls spliced?
No. Standard 25 m rolls are splice-free, and the width is held within ±0.5 mm at both ends. If you are running a fixed guide or a slitter, ask for the width measured at the core and at the outside of the roll on the lot report.
Can you slit to a width that is not on the list?
Yes, from 10 mm up to 150 mm in 1 mm steps. Slitting runs on a tension-controlled line at the mill, so a custom width does not add lead time once the master roll exists.
What is the minimum order and lead time?
Minimum order for this item is 500 rolls. Production runs 15–25 days after sample approval, with samples typically shipped in 7 days.
