Heavy-Duty Webbing Strap – 38 mm x 50 cm, Grey
38 mm x 50 cm grey piece, 4.8 N/25 mm peel, ±0.3 mm die-cut tolerance.
| Construction | Heavy-Duty Webbing Strap |
| Width | 38 mm |
| Length | 50 cm |
| Colour | Grey |
| Minimum order | 500 rolls |
Not ready to ask for a price? Just ask a question — an engineer replies, not a sales script.
Specification
| Construction | Heavy-Duty Webbing Strap |
|---|---|
| Width | 38 mm |
| Length | 50 cm |
| Colour | Grey |
| Weight / piece | 11.4 g |
| Peel strength | 4.8 N/25 mm |
| Shear strength | 18 N/cm² |
| Cycle life | 8,000 cycles |
| Service temperature | -20 °C to 85 °C |
| Pieces per carton | 500 |
| Minimum order | 500 rolls |
| Production lead time | 15-25 days after sample approval |
| Packing | Poly bag + carton, palletised for LCL |
| Certification | REACH, RoHS; OEKO-TEX on request |
What makes it different
- 38 mm width held to ±0.5 mm across the full run
- 4.8 N/25 mm peel measured on every lot
- Each piece weighs about 11.4 g; 500 pieces to a carton.
Other sizes in this construction
Same build, different width or length. Mixed sizes in one carton are fine.
| Size | Colour | MOQ |
|---|---|---|
| 50 mm x 80 cm | Black | 500 rolls |
| 50 mm x 50 cm | Grey | 500 rolls |
| 50 mm x 200 cm | Grey | 500 rolls |
| 38 mm x 80 cm | Grey | 500 rolls |
| 38 mm x 100 cm | Black | 500 rolls |
| 38 mm x 200 cm | Black | 500 rolls |
| 38 mm x 150 cm | Black | 500 rolls |
| 38 mm x 150 cm | Sand | 500 rolls |
| 50 mm x 150 cm | Black | 500 rolls |
| 38 mm x 100 cm | Sand | 500 rolls |
Need a custom width or die profile?
Send a drawing and we will confirm tooling cost and tolerance before you commit.
Talk to an engineerAbout this product
This is a stock construction: 600 g/m² face, 4.8 N/25 mm peel and 8,000 open-close cycles before the hook flattens. Typical use is seating, upholstery, automotive trim and load-bearing seams. Service temperature runs -20 °C to 85 °C.
Each piece weighs about 11.4 g; 500 pieces to a carton. Tolerance on width is ±0.5 mm, on die-cut profile ±0.3 mm.
Ordering and shipping
- Sold by the roll, carton or pallet — mixed widths allowed.
- EXW Xiamen, FOB or CIF to your port.
- T/T 30% deposit, balance against copy of B/L.
- Sample orders ship by courier in 7 days.
Choosing this construction
Match the strap to what it wraps, not to the load alone. Bundles under 30 mm do better with 12–16 mm ties, cable runs and tool handles with 20–25 mm, and anything carrying weight with 38 mm and a buckle rather than a tie. A strap that is too wide will not cinch tight enough to stop movement.
Common questions
What is 38 mm hook and loop used for?
At 38 mm this construction is normally specified for seating, upholstery, automotive trim and load-bearing seams. The width does not change the peel per unit width much, but narrower tape engages fewer hooks at the edge, which is where peeling starts — so if the joint opens repeatedly, go up one width rather than up one grade.
Buckle or tie — which one?
A tie is faster to fit and cheaper, and is right for anything a technician opens daily. A buckle holds tension better and is what to specify when the strap has to stay tight under load without being re-adjusted. We supply both from the same webbing.
Can the straps be printed with our logo?
Yes, from 1,000 pieces on woven webbing. Send vector artwork; we will confirm the print area against the strap width before tooling.
What is the minimum order and lead time?
Minimum order for this item is 500 rolls. Production runs 15–25 days after sample approval, with samples typically shipped in 7 days.
More in Straps, Ties & Cinches
Straps, Ties & Cinches
Reusable Hook and Loop Cable Tie – 12 mm x 45 cm, Red
12 mm x 45 cm red piece, 2.5 N/25 mm peel, ±0.3 mm die-cut tolerance.
MOQ 5,000 pcs
Straps, Ties & Cinches
Back-to-Back Hook and Loop Strap Roll – 25 mm x 25 m, White
